The JV240040 three-way, T-Ported stainless steel ball valve complies with ANSI standards, ensuring compatibility with ANSI 150 flange specifications, specifically designed to ensure reliable and efficient performance across a wide range of applications where fluid diversion and control are essential for operational success. This valve is supplied completely assembled with either a single (spring return) or double-acting JV-P pneumatic actuator.
All valve and actuator packages are tested and, on request, can be issued with certification confirming the actuators’ functionality before despatch.
| Size & Connections | DN15-DN150mm (1/2″-6″) • Flanged ANSI 150 |
| Valve Type | 3-Way T-Ported Full Bore Ball Valve |
| Actuator Type | Pneumatic • 90° Turn • Rack & Pinion • Single Acting (Spring Return) • Double Acting |
| Air Supply Range | 2.5 to 8 Bar |
| Valve Materials | Stainless Steel Body • PTFE Seat • Stainless Steel Ball |
| Applications | Air • Gas • Oil • Steam • Water |
| Pressure & Temperature* | 20 Bar • -20°C to 200°C |
| Approvals | ATEX Approved** • SIL3 Safety Integrity Level 3** |
*Dependent on size, pressure & temperature – see datasheet **Actuator only
 |
 |
 |
|||
| Download PDF Datasheet | ATEX Approved | SIL3 Safety Integrity Level 3 |
The JV240040 three-way, T-Ported stainless steel ball valve complies with ANSI standards, ensuring compatibility with ANSI 150 flange specifications, specifically designed to ensure reliable and efficient performance across a wide range of applications where fluid diversion and control are essential for operational success. This valve is supplied completely assembled with either a single (spring return) or double-acting JV-P pneumatic actuator.
All valve and actuator packages are tested and, on request, can be issued with certification confirming the actuators’ functionality before despatch.
| Size & Connections | DN15-DN150mm (1/2″-6″) • Flanged ANSI 150 |
| Valve Type | 3-Way T-Ported Full Bore Ball Valve |
| Actuator Type | Pneumatic • 90° Turn • Rack & Pinion • Single Acting (Spring Return) • Double Acting |
| Air Supply Range | 2.5 to 8 Bar |
| Valve Materials | Stainless Steel Body • PTFE Seat • Stainless Steel Ball |
| Applications | Air • Gas • Oil • Steam • Water |
| Pressure & Temperature* | 20 Bar • -20°C to 200°C |
| Approvals | ATEX Approved** • SIL3 Safety Integrity Level 3** |
*Dependent on size, pressure & temperature – see datasheet **Actuator only
JV240040 Pneumatically Actuated 3-Way T-Ported Stainless Steel Ball Valve – ANSI Datasheet (PDF)
