JV240002
Pneumatically Actuated Wafer Butterfly Valve – EPDM Lined

The JV240002 is designed as a highly dependable valve, featuring WRAS approval for use in potable water applications and other similar duties. Constructed with an EPDM liner, it offers durability and minimises maintenance requirements. Furthermore, the self-lubricating bearings ensure optimal guidance, facilitating smooth rotation of the shaft and significantly reducing the risks of seizure and premature wear during prolonged use. This valve is supplied completely assembled with either a single (spring-return) or double-acting JV-P pneumatic actuator.

All valve and actuator packages are tested and, on request, can be issued with certification confirming the actuators’ functionality before despatch.

Size & Connections	DN25-DN300 (1″-12″) • PN6, 10 & 16 • ANSI 150 • BS10 D & E • JIS 10K
Valve Type	Wafer Multi-Flange Butterfly Valve • Length to EN558-1 Series 20
Actuator Type	Pneumatic • 90° Turn • Rack & Pinion • Single Acting (Spring Return) • Double Acting
Air Supply Range	2.5 to 8 Bar
Valve Materials	Ductile & Cast Iron Body • Stainless Steel Disc • EPDM Liner
Applications	Potable (Drinking) Water
Pressure & Temperature*	10/16 Bar • -10°C to 120°C
Approvals	WRAS (CBF/J9 Range) • ATEX Approved* • SIL3 Safety Integrity Level 3***

*Dependent on size, pressure & temperature – see datasheet **Valve only ***Actuator only


Download PDF Datasheet	ATEX Approved	SIL3 Safety Integrity Level 3	WRAS Approved Valve
